01. Product application: Chocolate Packing Machine

SUNTECH fully automatic rotary packaging machine with multi head weigher, it is suitable to use in packing all kinds of grain material, sheet material, strip material and abnormity material which such as candy, seeds, chips, nuts, nuts, dry fruit, jelly, biscuits, potato chips, pet food, grain, cereal, dilatant foodstuff, small hardware and plastic can be weighed by the ration.

According to customer needs,the machine can use stand up bag, gusset bag, zipper bag, pouch,three sides seal, four side seal etc. bag types.

02. Product feature: Chocolate Packing Machine

1.Easy to operate,adopt advanced PLC from Germany Siemens,  mate with touch screen and electric control system, the man-machine interface is friendly.

2.Frequency conversion adjusts the speed: this machine uses frequency conversion equipment, can be adjusted within the range according to the needs of reality in production.

3.Automatic checking: no pouch or pouch open error, no fill, no seal. the bag can be used again, avoid wasting packing materials and raw materials.

4.Safty device: Machine stop at abnormal air pressure, heater disconnection alarm.

5.Horizontal conveyor style to giving bag: it can put on more bags on the bag storage and have a low requirement about the quality of bags.

6.The width of the bags could be adjusted by electrical motor. Press the control-button could adjust the width of all clips, easily operate, and raw materials.

7.The packing materials loss low, what this machine is used the preformed bag, the bag pattern is perfect and  has a  high quality of the sealing part, this improved the product specification



03. Machine Specification: Chocolate Packing Machine

Model	SUN-S8-200
Working position	Eight-working position
Pouch material	Laminated film\PE\PP etc.
Pouch pattern	Flat pouch, 3 or 4 sealing bag, stand up bag, gusset bag etc.
Pouch size	W:100-200mm L:100-300mm
Speed	Up to 50 pouches/min(The speed depends on the product status and filling weight)
Weight	1250KGS
Voltage	380V 3phase 50HZ or customer customized
Total power	3.5KW
Compress air	0.4m3/min(supply by user)
Size	2200*1850*1500mm



Working Processing of Chocolate Packing Machine

Packaging & Shipping: Chocolate Packing Machine

• Packaging: machinery standard packaging or customized.
• Shipping: By Air, by Sea or by Express (DHL etc) Shipment cost will depend on the destination, shipment way and the weight of the goods.

>>Trade terms:

• Delivery Time: 20-30 Days.
• Please tell us quote EXW,FOB,or CIF price? Which port is very impotant.
• Payment: T/T, 30% deposits, 70% balance before deliverying. L/C acceptable.



Kindly reminder:

Please let us know the follow packing details when you offer,so that we can check if this model is suitable for your case.Thank you in advance.

1. Product details & weight

2. Bag width,bag length

3. Bag shape

4. Packing film/ pouch material

What is A Chocolate Packing Machine?

This chocolate packing machine is a type of doypack machine that can pack the chocolate very well. The chocolate packing machine is composed of a multi-head weigher, a Z-shaped bucket elevator, a working platform, a touch control screen, and a doypack machine.

What are the Features of A Chocolate Packing Machine?

This chocolate packing machine guide you to step into a new era of packing industry. Here are main features of a chocolate packing machine.

●User-Friendly Operation

Equipped with advanced PLC technology sourced from Germany's Siemens, this machine boasts a user-friendly interface through its touch screen and electric control system. Operating this marvel is a breeze, offering an intuitive man-machine interaction that simplifies the packaging process.

●High Packing Efficiency

One of its standout features is the ability to adjust speed through frequency conversion, allowing real-time adaptation to production needs. This adaptability ensures optimal performance and efficiency, achieving up to 50 pouches per minute while maintaining precision and quality.

●Variety in Package Methods

The versatility of this chocolate packing machine extends to its horizontal conveyor style, accommodating various pouch types including flat pouches, 3 or 4 sealing bags, stand-up bags, and gusset bags. Its adaptability to different pouch materials like laminated film, PE, and PP further enhances its versatility.

With adjustable bag width using an electrical motor, the ease of customization is at your fingertips. Simply press a control button to modify the width of all clips, streamlining the process and minimizing raw material wastage.

What is the Working Process of A Chocolate Packing Machine?

Giving Bag - Coding - Opening - Fill Consolidate - Auxiliary - Heat Sealing - Forming & Output Product.

Packaging & Trade Terms: Chocolate Packing Machine

Step 1: Clean

Step 2: Warning Sign & Oil

Step 3: Stretch Film

Step 4: Wooden Case

Step 5: Mark

Step 6: Loading

Step 7: Delivery
