Granule Vertical Filling Machine | Food Packing Machine Manufacturer - Suntech
Leading food packing machine manufacturer offering advanced vertical filling machines for efficient, precise packaging solutions across various food products.
Product Description
It is suitable to use in packing the high accuracy and easy fragile material. Such as: puffy food,chips, jelly, candy, pistachio nuts, nuts, apple slices, frozen dumpling, coffee beans, pasta,cotton candy, french fries, rice, pet food, small hardwares, etc.
|
Model
|
SUN-320 |
SUN-420 |
SUN-520 |
SUN-720 |
|
Packing Speed
|
5-60 Bags/Min
|
|
Volume(ML)
|
800
|
1000
|
2000
|
5000
|
|
Bag Width(MM)
|
50-150
|
60-200
|
80-250
|
150-350
|
|
Bag Length(MM)
|
80-200
|
80-300
|
80-400
|
80-450
|
|
Max Width Of Roll Film(MM)
|
320
|
420
|
520
|
720
|
|
Thickness
|
0.04-0.09 MM
|
|
Material
|
OPP/CPP PET/PE PET-AL/PE Lamination Film
|
|
Weight(KG)
|
350KG
|
450KG
|
550KG
|
750KG
|
|
Air Consumption
|
0.65Mpa 0.3m³/Min
|
0.65Mpa 0.4 m³/Min
|
0.8Mpa 0.4m³/Min |
0.8Mpa 0.4m³/Min
|
|
Power Supply(KW)
|
2.2
|
2.2
|
2.2
|
3.0
|
|
Dimension LxWxH(MM)
|
1170X820X1285 |
1320X920X1392 |
1500X1140X1540 |
1800x1250x1780 |
|
Temperature Precision
|
±1℃
|
|
Weighing Precision
|
±0.5~±2.0g |
Our affordable, easy to use packaging machine are suitable for company wanting to automate their packaging processes for the first time or to the larger producer looking for more productivity and efficiency.
How to Delivery
We use non fumigation pallets plywood cases to pack machines.
Our Service
✔ Pre-Sale Service:
We will according your product feature, weight of each bag, and shape of bag make a quotation for you. Then more details we need communication such as material and thickness of film, dimension of bag you already have it or need we design for you, Operate language,what kind of voltage at the local.
✔ After-Sale Service:
Warranty: 2 Years except wearing parts ( Cutter, Belt, Horizontal and vertical Heating Tube etc), Most of components are free-replacement (PLC, Servo controller, Servo motor, Touch screen, Cylinder). Machine delivery will with a tool box, there have some parts are free.
Operation training:
1: Machine is very easy operate, delivery with manual, offer lots of photos and videos when machine in assembling or disassembling.
2: Welcome to our factory learning.
3: Engineers available to service machinery overseas.
About Suntech
We has gained rich experience in the packing machinery field and has many mature technologies. So far, dozens of packaging machine series have been successfully developed to achieve the optimal matching of automatic weighing machines and packaging machines. It is widely used in Food, Beverage, Pharmaceutical ,Chemical, Hardware accessories and other industries. It is the preferred equipment to achieve production automation and improve production efficiency. At present, the products are exported to Europe, America, Middle East, Southeast Asia, Africa and other parts of the world, and are deeply trusted and praised by users.
We not only provide customers with high quality and reliable products, but also design and manufacture packaging equipment according to customers' actual requirements, provide packaging overall solutions, undertake various standard packaging machines OEM business, and provide professional technical service support for customers. To create greater value for customers.
"Strictly Abide by the Integrity, the Pursuit of Excellence", all the Suntech people must take it as their conviction and serve the customers wholeheartedly, warmly welcome customers at home and abroad to visit and guide, we hope to create brilliant success together with you!
Certifications
